Leading SF₆-free Gas-Insulated Switchgear for Sustainable Power Distribution
Nuventura manufactures SF₆-free gas-insulated switchgear (GIS) for 24 kV and 36 kV medium-voltage applications.
Our pioneering dry-air insulation technology eliminates SF₆ greenhouse gas while delivering industry-leading performance: 2500 A rated busbar current capacity, full IEC 62271-certification, and maintenance-free operation. As the leading SF₆-free switchgear manufacturer, we provide environmentally friendly alternatives to traditional gas-insulated switchgear without compromising reliability or performance.
Our innovative medium-voltage switchgear solutions replace SF₆ – the world's strongest greenhouse gas – with pure dry air whilst using vacuum circuit breakers, ensuring complete compliance with EU F-gas regulations and future environmental standards.
Nuventura joins Lucy Electric to accelerate global adoption of SF₆-free primary switchgear
Trusted by the industry's top innovators
Proudly ISO Certified for Quality Excellence in Switchgear Manufacturing
.avif)
Why Choose SF₆-Free Medium-Voltage Switchgear?
IEC-certified SF₆-free gas-insulated switchgear (GIS) engineered for reliability,
compliance and optimal life-cycle performance.
Environmental Compliance & Future-Proof Technology
Nuventura's SF₆-free switchgear keeps utilities and industrial operators fully aligned with the tightening regulation around SF₆ in gas-insulated switchgear, including the EU F-gas Regulation. By replacing the insulating medium SF₆ with dry air, it removes the substance with the highest global warming potential in industrial use, cutting emissions and reducing the carbon footprint of the network without altering proven GIS behaviour. As a future-proof SF₆ alternative switchgear, it lets operators stay ahead of the SF₆ phase-out instead of retrofitting later.
IEC 62271-Certified Performance Standards
Every Nu1 medium-voltage switchgear unit undergoes rigorous IEC 62271-200 certification testing, guaranteeing reliable performance for critical power distribution infrastructure. Our type-tested designs meet the highest international standards for 24 kV and 36 kV voltage classes, ensuring safety and reliability across all applications.
Rapid Delivery & Installation Timeline
Experience seamless system integration with our modular switchgear architecture and standardized 20-to-28-week delivery timeline. Our compact footprint design optimizes space utilization while maintaining full compatibility with existing electrical infrastructure, making Nuventura the preferred choice for time-sensitive projects.
Maintenance-Free Dry-Air Technology
Advanced dry air insulated switchgear technology ensures maintenance-free operation throughout the equipment lifecycle, reducing operational costs and maximizing system uptime for utilities, renewable energy projects, and industrial applications. Unlike traditional SF₆-based systems, our dry-air insulation requires no gas monitoring, refilling, or special handling procedures.
Nu1 – primary distribution for 24 kV and 36 kV (single busbar)
Nu1 is a fully type-tested, SF₆-free medium-voltage gas-insulated switchgear, optimized for indoor primary distribution applications.
It features an outercone connection system, a solid-insulated busbar, and a single-tank design, delivering a compact layout, high operational reliability, and simplified installation.
Engineered with dry-air insulation and fully compliant with IEC 62271, Nu1 provides climate-friendly, maintenance-free performance while preserving the proven characteristics of conventional primary GIS. As an 24 kV and 36 kV gas-insulated switchgear solution, it brings
SF₆-free electrical switchgear to modern power grids.
Technical certification
IEC 62271-200 certified for both voltage classes with type-tested performance.
Performance rating
31.5kA/3s short-circuit rating with 2500A rated busbar current.
Insulation technology
Pure dry-air insulation system, engineered for sustainable, maintenance-free operation.
System integration
Compact footprint with standardized interface for existing infrastructure.
Nu1 Technical Specifications
Our gas-insulated switchgear (GIS) combines proven engineering with sustainable innovation
IEEE C37.04
IEEE C37.04
900 mm (2000 A)
900 mm (2000 A)
Nu2 – primary distribution for
24 kV (single and double busbar)
Nuventura’s specialized 24 kV variants are designed in full compliance with IEC and ANSI/IEEE standards, ensuring suitability for global utility applications.
They include Single Busbar (SBB) and Double Busbar (DBB) configurations, with rated currents of 1250 A and 2500 A, to address a wide range of utility requirements.
Key features include inner cone cable terminations, segregated vacuum circuit breaker (VCB) and disconnector/busbar compartments, and a gas-insulated busbar design, enhancing operational safety, reliability, and compactness.
✓
✓
✓
Nu2 Technical Specifications
Double Busbar
ANSI/IEEE C37.20.9
ANSI/IEEE C37.20.9
900 mm (2500 A)
900 mm (2500 A)
2650 mm (DBB)
2650 mm (DBB)
2200 mm (DBB)
2200 mm (DBB)
Where our SF₆-free technology is
making a difference
Explore successful implementations across utilities, renewable energy, data centers and industrial applications worldwide.
Driving the SF₆-free revolution in power distribution
Founded to eliminate SF₆ from power distribution, Nuventura combines leading switchgear expertise with sustainable innovation. Our pioneering dry-air technology delivers environmental responsibility without compromising performance, driving the industry's transformation toward a sustainable future.
.webp)
Project Enquiries
Whether it’s SF₆-free switchgear specifications, partnership opportunities or support – our team is ready to answer your questions and find the right eco-friendly solution for your needs.
If you are evaluating SF₆-free switchgear for a new project or looking to replace conventional GIS, our team can help you define the right technical solution. We support customers with product specifications, project planning, partnership discussions and technical clarification throughout the decision-making process. Whether the application is utility, industrial or renewable energy, we work with you to identify the most suitable configuration for your requirements. Contact us to discuss your project in more detail and explore the best SF₆-free option for your application.
